        Product Code: 10m-xp-xreel
        You must be logged in.

        M-XP™ Million Impulse hose is designed for high-pressure, high impulse life hydraulic applications.

        Description

        • Recommended For: High-pressure, high impulse life hydraulic applications.
        • For use with GlobalSpiral™ Couplings [G20 Series] and MegaCrimp™ Couplings [G25 Series].
        • Provides bend radius up to 1/3 of the SAE specifcation and greater flexibility for easier routing.
        • Tested to industry-leading 1,000,000 impulse cycles.
        • 4000 psi working pressure for all sizes.
        • Meets Flame Resistance Acceptance Designation MSHA 2G.

        Additional information

        Weight 111.32 lbs
        Dimensions 18 × 18 × 17.5 in
        Automative Part Number

        71108

        Product Number

        46574219

        Hose Pressure

        Constant Pressure-High

        Tube Material

        Nitrile – Type C

        Tube Characteristics

        Hyd Fluids, Phosphate Esters, Water Glycol

        Reinforcement

        2-braid, wire

        Cover Type

        Standard

        Cover Material

        Polychloroprene (Neoprene) – Type A

        Cover Color

        Black

        Tube Color

        Black

        Min Temp ©

        -40

        Max Temp ©

        100

        Min Temp (F)

        -40

        Max Temp (F)

        212

        Dash Size

        10

        Hose ID (in)

        0.625

        Hose ID (mm)

        15.9

        Hose OD (in)

        0.96

        Hose OD (mm)

        24.4

        Length (ft)

        220

        Length (m)

        67

        Dynamic WP (psi)

        4000

        Dynamic WP (bar)

        275.8

        Min. Burst Pressure (psi)

        16000

        Min. Burst Pressure (bar)

        1103.2

        Min. Bend Radius (in)

        4

        Min. Bend Radius (mm)

        101.6

        Coupling Recommendation 1

        MegaCrimp® Couplings [G25 Series]

        Coupling Recommendation 2

        GlobalSpiral™ Couplings [G20 Series]

        Meets MSHA 2G

        YES

        GC Base Product

        M-XP™ Million Impulse Xtra Performance Wire Braid Hose
