12PROXT XREEL
Product Code: 12proxt-xreel
You must be logged in.
Gates PRO™ Series ProXT™ variable pressure hydraulic hoses offer performance specifically tailored to hydraulic applications across multiple end markets. All sizes deliver consistent performance to SAE, ISO and EN industry specifications. ProXT™ hoses are qualified for use with the full line of PRO™ Series couplings to ensure end-to-end performance — providing a broad range of engineered solutions for targeted hydraulic applications.
Options
Description
- Qualified with existing Gates PRO™ Series hoses in sizes ranging from -4 to -16 offering a complete hydraulic system solution.
- Multi-purpose solution meets SAE 100R16, ISO 11237 R16, as well as SAE 100R2 and EN857 2SC performance standards.
- Manufactured to Gates high-quality professional standards.
- Provides reliable performance for standard duty applications in industries such as agriculture, construction, mining and manufacturing.
- Ideal for non-severe, high-pressure hydraulic applications with low flexure requirements.
- Compact design is more flexible and lighter weight for easier handling and faster installation.
- System designs can be evaluated and optimized by our experts to ensure you get the right product for the application.
- Meets MSHA Flame Resistance.
Additional information
| Weight | 103.4 lbs |
|---|---|
| Dimensions | 20 × 20 × 17.5 in |
| Product Number | 46579949 |
| Hose Pressure | Variable Pressure-High |
| Tube Material | Nitrile |
| Reinforcement | High-tensile steel wire braid |
| Cover Type | Standard |
| Cover Material | Nitrile, PVC Synthetic Rubber |
| Cover Color | Black |
| Tube Color | Black |
| Min Temp © | -40 |
| Max Temp © | 100 |
| Min Temp (F) | -40 |
| Max Temp (F) | 212 |
| Dash Size | 12 |
| Hose ID (in) | 0.75 |
| Hose ID (mm) | 19.1 |
| Hose OD (in) | 1.08 |
| Hose OD (mm) | 27.4 |
| Length (ft) | 220 |
| Length (m) | 67 |
| Dynamic WP (psi) | 3125 |
| Dynamic WP (bar) | 215.46 |
| Min. Burst Pressure (psi) | 12500 |
| Min. Burst Pressure (bar) | 862 |
| Min. Bend Radius (in) | 4.8 |
| Min. Bend Radius (mm) | 121.9 |
| Coupling Recommendation 1 | Pro Series Couplings |
| ISO Spec 1 | 11237 R16 |
| EN Spec 1 | 857 2SC |
| SAE Spec 1 | 100R16 |
| SAE Spec 2 | 100R2 |
| Meets MSHA 2G | YES |
| GC Base Product | ProXT™ – Wire Braid Hose – SAE 100R16 / SAE 100R2 |
