        Product Code: 3-8-x-250ft-reel-gs-air-brake
        You must be logged in.

        Green Stripe® Vacuum Brake Hose is an extra heavy–duty hose designed to fit most air brake systems on trucks, trailers and other heavy equipment.

        Description

        • Recommended For: Truck, bus and mobile air brake systems. Can be used as flexible connector between frame and axle.
        • Exceeds SAE J1403, Type H requirements.
        • Complies with DOT FMVSS 106VH requirements.

        Additional information

        Weight 56.51 lbs
        Dimensions 28.5 × 28.5 × 7.5 in
        Automative Part Number

        28304

        Product Number

        32454470

        Hose Pressure

        Constant Pressure-Low

        Tube Material

        Polychloroprene (Neoprene)

        Reinforcement

        2-braid, fiber

        Cover Type

        Standard

        Cover Material

        Polychloroprene (Neoprene)

        Cover Characteristic

        Smooth

        Cover Color

        Black

        Tube Color

        Black

        Min Temp ©

        -40

        Max Temp ©

        100

        Min Temp (F)

        -40

        Max Temp (F)

        212

        Dash Size

        6

        Hose ID (in)

        0.375

        Hose ID (mm)

        9.5

        Hose OD (in)

        0.75

        Hose OD (mm)

        19.1

        Length (ft)

        250

        Length (m)

        76

        Dynamic WP (psi)

        225

        Dynamic WP (bar)

        15.5

        Min. Burst Pressure (psi)

        1000

        Min. Burst Pressure (bar)

        68.9

        SAE Spec 1

        J1402

        Other Spec

        Exceeds Bendix specifications

        DOT

        DOT FMVSS 106

        GC Base Product

        Rubber Air Brake Hose
