4G2XH X50FT
Global G2XH hose is recommended for extremely high-temperature, high-pressure hydraulic applications where pressure or temperature requirements exceed SAE 100R2, ISO 1436 2SN R2 and EN 853 2SN or where resistance to either petroleum base or phosphate ester fluids is required. Compatible with biodegradable hydraulic fluids like polyolester, polyglycols and vegetable oils as well as petroleum-based fluids and phosphate esters.
Description
- Recommended For: Extremely high-temperature high-pressure hydraulic applications where pressure or temperature requirements exceed SAE 100R2, ISO 1436 2SN R2 and EN 853 2SN or where resistance to either petroleum-base or phosphate ester fluids is required.
- For use with GlobalSpiral™ Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp™ Couplings [G25 Series] and Stainless Steel Braid Couplings [G17 Series].
- Blue, oil- and abrasion-resistant, thin synthetic rubber cover indicates higher temperature hose.
- Tested to industry-standard 600,000 impulse cycles.
- Meets Flame Resistance Acceptance Designation MSHA 2G.
Additional information
Weight | 13 lbs |
---|---|
Dimensions | 18.375 × 18.375 × 3.25 in |
Automative Part Number | 85798 |
Product Number | 46574008 |
Hose Pressure | Variable Pressure-High |
Tube Material | CPE – Type J |
Tube Characteristics | Hyd Fluids, Phosphate Esters, Water Glycol |
Reinforcement | 2-braid, wire |
Cover Type | Standard |
Cover Material | CSM – Type M |
Cover Color | Blue |
Tube Color | Black |
Min Temp © | -40 |
Max Temp © | 149 |
Min Temp (F) | -40 |
Max Temp (F) | 300 |
Dash Size | 4 |
Hose ID (in) | 0.25 |
Hose ID (mm) | 6.4 |
Hose OD (in) | 0.59 |
Hose OD (mm) | 15 |
Length (ft) | 50 |
Length (m) | 15 |
Dynamic WP (psi) | 6000 |
Dynamic WP (bar) | 413.7 |
Min. Burst Pressure (psi) | 24000 |
Min. Burst Pressure (bar) | 1654.7 |
Min. Bend Radius (in) | 4 |
Min. Bend Radius (mm) | 101.6 |
Coupling Recommendation 1 | GlobalSpiral™ Couplings [G20 Series] |
Coupling Recommendation 2 | MegaCrimp® Couplings [G25 Series] |
ISO Spec 1 | 1436 2SN R2 |
EN Spec 1 | 853 2SN |
SAE Spec 1 | 100R2 |
SAE Spec 2 | J1942 |
Meets MSHA 2G | YES |
Temp Note 1 | Petroleum-Base Fluid |
Temp Note 2 | Phosphate Ester Fluids to +212°F |
GC Base Product | Global G2XH 2-Wire Braid Xtreme® Heat Hose – SAE 100R2 Type S |
