6CM2TDL-XTF X50FT
CM2T Dual-Line hose is recommended for high pressure and return lines such as boom arm and forklift applications, as well as high abrasive high-pressure hydraulic oil lines that are joined together for easier plumbing and routing. Smaller exterior dimensions and signifcantly tighter bend radius. CM2T Dual Line hose is compatible with biodegradable hydraulic fluids like polyolester, polyglycols and vegetable oils as well as petroleum-based fluids. CM2TDL-XTF hose has smaller exterior dimensions and signifcantly tighter bend radius and lasts up to 25 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945.
Description
- Recommended For: High abrasion resistant high-pressure hydraulic oil lines.
- For use with GlobalSpiral™ Couplings [G20 Series] and MegaCrimp™ Couplings [G25 Series].
- No need to use clamps as the two lines are vulcanized together to form one single unit.
- Provides bend radius up to 1/3 of the SAE specifcation and greater flexibility for easier routing.
- Tested to industry-leading 600,000 impulse cycles.
- XtraTuff™ hose lasts up to 25 times longer than standard hose.
- Meets Flame Resistance Acceptance Designation MSHA 2G.
Additional information
Weight | 30.81 lbs |
---|---|
Dimensions | 20.625 × 20.625 × 5.75 in |
Automative Part Number | 85389 |
Product Number | 46574980 |
Hose Pressure | Variable Pressure-High |
Tube Material | Nitrile – Type C |
Tube Characteristics | Hyd Fluids, Phosphate Esters, Water Glycol |
Reinforcement | 2-braid, wire |
Cover Type | XtraTuff |
Cover Material | XtraTuff |
Cover Color | Black |
Tube Color | Black |
Min Temp © | -40 |
Max Temp © | 100 |
Min Temp (F) | -40 |
Max Temp (F) | 212 |
Dash Size | 6 |
Hose ID (in) | 0.375 |
Hose ID (mm) | 9.5 |
Hose OD (in) | 0.7 |
Hose OD (mm) | 17.8 |
Length (ft) | 50 |
Length (m) | 15 |
Dynamic WP (psi) | 4800 |
Dynamic WP (bar) | 330.9 |
Min. Burst Pressure (psi) | 19200 |
Min. Burst Pressure (bar) | 1323.8 |
Min. Bend Radius (in) | 3.5 |
Min. Bend Radius (mm) | 88.9 |
Coupling Recommendation 1 | MegaCrimp® Couplings [G25 Series] |
Coupling Recommendation 2 | GlobalSpiral™ Couplings [G20 Series] |
ISO Spec 1 | 11237 2SC R16 |
ISO Spec 2 | 1436 2SN R2 |
EN Spec 1 | 857 2SC |
SAE Spec 1 | 100R16 |
Meets MSHA 2G | YES |
GC Base Product | CM2TDL MegaFlex® Connected Twin-Line 2-Wire Braid Hose – SAE 100R16 – XtraTuff® Cover |
