24G2H X50FT
Product Code: 24g2h-x50ft
You must be logged in.
G2H hose is recommended for high-temperature, high-pressure hydraulic oil line applications.
Options
Description
- Recommended For: High-temperature high-pressure hydraulic oil lines.
- For use with Field Attachable Type T Couplings [G28 Series], GlobalSpiral™ Couplings [-20 G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp™ Couplings [G25 Series] and Stainless Steel Braid Couplings [G17 Series].
- Tested to industry-standard 600,000 impulse cycles.
- MegaTuff™ hose lasts up to 300 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945 and offers superior ozone and weathering resistance.
- Meets Flame Resistance Acceptance Designation MSHA 2G.
Additional information
| Weight | 90.06 lbs |
|---|---|
| Dimensions | 40 × 40 × 5 in |
| Automative Part Number | 86518 |
| Product Number | 46570927 |
| Hose Pressure | Variable Pressure-High |
| Tube Material | Nitrile – Type C |
| Tube Characteristics | Hyd Fluids, Phosphate Esters, Water Glycol |
| Reinforcement | 2-braid, wire |
| Cover Type | Standard |
| Cover Material | CSM – Type M |
| Cover Color | Black |
| Tube Color | Black |
| Min Temp © | -40 |
| Max Temp © | 135 |
| Min Temp (F) | -40 |
| Max Temp (F) | 275 |
| Dash Size | 24 |
| Hose ID (in) | 1.5 |
| Hose ID (mm) | 38.1 |
| Hose OD (in) | 2.11 |
| Hose OD (mm) | 53.6 |
| Length (ft) | 50 |
| Length (m) | 15 |
| Dynamic WP (psi) | 1300 |
| Dynamic WP (bar) | 89.6 |
| Min. Burst Pressure (psi) | 5200 |
| Min. Burst Pressure (bar) | 358.5 |
| Min. Bend Radius (in) | 20 |
| Min. Bend Radius (mm) | 508 |
| Coupling Recommendation 1 | GlobalSpiral™ Plus Couplings [G22 Series] |
| Coupling Recommendation 2 | Stainless Steel Braid Couplings [G17 Series] |
| Coupling Recommendation 3 | Field Attachable Type T Couplings [G28 Series] |
| ISO Spec 1 | 1436 2SN R2 |
| EN Spec 1 | 853 2SN |
| SAE Spec 1 | 100R2 |
| Meets MSHA 2G | YES |
| GC Base Product | Global G2H High-Temp 2-Wire Braid Hose – Type AT |
